PVCHECKS-ONE

Commissioning tester for PV system up to 1000V / 30A

PVCHECKs-ONE

Advanced instrument for commissioning tests and fault finding on live photovoltaic systems

  • PVCHECKs-ONE includes the innovative OPT function designed to perform insulation testing also on PV system strings where MLPEs (power optimizers with or without RSD) are installed, without the need to disconnect these devices from the modules.
    This new function extends the versatility of the instrument and ensures compliance with safety and performance requirements in modern photovoltaic systems integrating power electronics.
    The function complies with rapid shutdown device (RSD) requirements in accordance with the reference standard NEC 690.12.
  • Single and simple “GO” command to perform all commissioning tests automatically
  • Testing on mono- and bifacial modules (including high-efficiency types) up to 1000 V / 30 A
  • Complete electrical safety checks on live installations: continuity, polarity, Voc, Isc, insulation resistance
  • Fault locator to identify between which modules an insulation problem is present
  • Autostart mode for sequential testing of all strings in a combiner box

The multifunction instrument PVCHECKs-ONE allows fast and safe execution of all electrical safety tests required for the DC side of a PV system, as well as functional verification of open-circuit voltage (Voc) and short-circuit current (Isc) of modules and strings, in compliance with IEC/EN 62446.
In the field of electrical safety testing, PVCHECKs-ONE represents a true innovation: thanks to the DUAL function, insulation resistance measurements can be performed on a single module, a string, or an entire PV array without the need for an external switch to short-circuit the positive and negative terminals.
The instrument also enables functional verification of PV connections and strings according to IEC/EN 62446 by measuring Voc and Isc under Operating Conditions (OPC) and referring the values to STC through irradiance measurement, including the use of the optional accessories SOLAR03 and HT305.
At the end of each test, an immediate result is provided, both in absolute terms and by comparison with previously tested strings, supporting a rapid assessment of the system status.

Functions
Continuity of protective circuit with 200mA
Polarity
Open circuit voltage Voc of PV modules and strings 1000V
Short circuit current Isc on PV modules and strings 30A
PV string/field insulation with test voltage 250, 500, 1000VDC
Use of SOLAR-03 remote unit with Bluetooth connection
Measurement of direct (front side) irradiation with reference cell with SOLAR03 remote unit (optional accessory)
Temperature measurement of cell and environment with SOLAR03 remote unit (optional accessory)
Measurement of polarization index P.I.
Dielectric absorption ratio D.A.R
GFL function to locate the fault position in the string
Measurement category CAT III 1000V
OPT function for insulation testing on PV strings in the presence of MLPE devices such as optimizers and RSDs, without the need to disconnect them from the modules
Backlit LCD display
Internal memory 999 Locations
Integrated WiFi
Optical/USB serial port for PC connection
Custom management of internal PV module database
Auto power off
Help on line on the display
Size (LxWx H) (mm) 235x165x75
Weight in grams (batteries included) 1200
Guidelines
  • CE MARK
  • IEC/EN61010-031
  • IEC/EN61010-1
  • IEC/EN61010-2-034
  • IEC/EN61187
  • IEC/EN61326-1
  • IEC/EN61557-1
  • IEC/EN61557-2
  • IEC/EN61557-4
  • IEC/EN62446-1
