The generation of voltage and current signals is also possible by using up to 3 selectable ramps. This model also allows measuring the current absorbed by external transducers directly supplied by it and simulating the presence of a transducer with adjustable current in its whole measuring range. HT8051 has been designed in compliance with safety standard IEC/EN61010-1 with double protective insulation, and each function can be selected through the appropriate buttons found on the front panel. This device is the ideal solution for typical industrial automation applications and for laboratory activities.
Measuring counts | |
TRMS | |
AC/DC voltage | MAX 10VDC |
AC/DC current | MAX 24mADC |
DC 4-20mA current measurement | |
DC 0-10V voltage measurement | |
DC 4-20mA current generation | |
DC 0-10V voltage generation | |
Measurement of output current of transducers | |
Simulation of an external transducer | |
Loop supply with minimum voltage 24V | |
Generation of selectable ramp | |
Backlit LCD display | |
Auto power off | |
Protection category | |
Weight in grams (batteries included) | |
Size (LxWxH) (mm) |
