EASYTEST | Multifunction

EASYTEST

Multifunction tester for electrical installation safety tests

EASYTEST carries out tests on electric systems in compliance with IEC/EN 61557-1 and therefore measurements of continuity of the protection cable, insulation resistance (with calculation of PI and DAR), overall earth resistance, RCDs type A and AC tripping time and current, line / fault impedance with calculation of prospective short circuit / fault current, phase sequence and conformity.

The instrument is provided with the innovative AUTO function: by selecting this function and only setting the value of RCD current, EASYTEST carries out tests of overall earth resistance, RCD tripping time and insulation resistance in a sequence. At the end of the test, the device shows all results with the indication of compliance or non-compliance with the standards with simple symbols OK or NOT OK.

The internal memory allows saving the measures and subsequently transfer them onto the PC through the optical/USB connection.

Functions
AUTO test (Non-trip ground resistance, RCD, Insulation) in sequence
Insulation with test voltages 100, 250, 500, 1000VDC
Measurement of dielectric absorption ratio D.A.R.
Measurement of polarization index P.I.
Continuity of protective conductors with 200mA
Tripping time of type A, AC General and Selective RCDs
Non-trip earth resistance
Loop/Line impedance, Phase-Phase, Phase-Neutral, Phase-PE
Contact voltage
Phase sequence
Help on line on the display
Internal memory for measured data saving
Optical/USB serial port for PC connection
Protection rating
Power supply
Protection category CAT IV 300V
Weight in grams (batteries included) 1200
Size (LxWxH) (mm) 222x162x57
Guidelines
  • 17th edition
  • CEI 64-8
  • CE MARK
  • EN60909-0
  • IEC/EN61010-031
  • IEC/EN61010-1
  • IEC/EN61010-2-030
  • IEC/EN61010-2-033
  • IEC/EN61010-2-034
  • IEC/EN61187
  • IEC/EN61326-1
  • IEC/EN61557-1
  • IEC/EN61557-10
  • IEC/EN61557-2
  • IEC/EN61557-3
  • IEC/EN61557-4
  • IEC/EN61557-6

STANDARD ACCESSORIES

OPTIONAL ACCESSORIES
