THT100 | Electrical & Mechanical application


Infrared thermal camera with resolution 80x80pxl

THT100 is the new professional thermal camera equipped with a high resolution 80 x 80pxl IR sensor which makes it suitable for use in electrical, mechanical, plumbing, ventilation and refrigeration systems. It is equipped with a measuring range of -20° C ÷ 650.0° C and a field of view of 21° x 21°, producing high quality thermal images and videos, as well as allowing AutoFusion and Picture in Picture functions.  The thermal imaging camera is equipped with a modern internal icon structure and a high brightness capacitive touch-screen display. It is also equipped with Wi-Fi connection, as well as being compatible with the new and convenient HT Pro Camera application.

IR Resolution 80 x 80 pxl
Temperature range -20° ÷ 650°C
Image frequency 50Hz
Thermal sensitivity / NETD <0.05°C @ 30°C / 50mK
Field of view (FOV) 21° x 21°
Focal length f 1.0
Lens 7.5mm
IFOV 4.53mrad
Focus mode focus free
Built-in camera 2 MP, focus free
Picture in Picture function
AutoFusion image enhancement
Uncertainty about the measure ±2°C (±3.6°F) o±2% of reading
Digital zoom 1x ÷ 32x
Measurement tools (in live mode) none, center spot, 3 spots, hot/cold spots, 3 areas, vertical and horizontal lines, screening mode
Area measurement information max, min, AVG
IR Video recording
Measurement corrections emissivity, reflected temperature, ambient temperature, atmospheric humidity, infrared compensation, distance compensation
Color Palettes iron, rainbow, white hot, black hot, brown hot, blue/red, hot/cold, feather, above max alarm, below min alarm, interval alarm
Span modes Automatic / Manual / Histogram
Internal memory 3,4 GB
On-camera report building text annotation
Communication modes USB type C, Wi-fi, SD card
Display touch screen
Battery operation time 4 hours
Size (LxWxH) (mm) 240 x 101 x 110mm
  • EMC 2014/30/EU
  • EMC: IEC/EN61326
  • IEC/EN61010-1
