HT8100 | TRMS

HT8100

Professional process calibrator/multimeter

Professional process calibrator/multimeter

Model HT8100 is a professional device which groups measurements such as TRMS multimeter and function of process calibrator capable of generating current signals DC 0-20mA and 4-20mA.

As a digital multimeter, the device mainly carries out AC/DC voltage and AC/DC current measurements. In its function as a current generator (values can be displayed also in a percentage format) options 0-20mA and 4-20mA are available, with manual and automatic settings of thresholds on the output signal. This model also allows measuring the current absorbed by external transducers directly supplied by it and simulating the presence of a transducer with adjustable current in its whole measuring range. HT8100 is capable of saving the results of measurements in its internal memory and has been designed in compliance with safety standard IEC/EN61010-1 in CAT III 1000V and CAT IV 600V with double protective insulation. Each function can be selected through the appropriate buttons found on the front panel. This device is the ideal solution for typical industrial automation applications.

Functions
Measuring counts
TRMS
AC/DC voltage 1000V anche AC+DC
AC/DC current 1A anche AC+DC
Resistance and buzzer continuity
Diode test
Frequency
DC 4-20mA current measurement
DC 0-10V voltage measurement
DC 4-20mA current generation
Measurement of output current of transducers
Simulation of an external transducer
Loop supply with minimum voltage 24V
Generation of selectable ramp
Load of 250Ω for testing HART transducers
Backlit LCD display
Autorange
Auto Power OFF
Data HOLD
MIN/MAX function
AVG function
Relative measurement
Protection category CAT IV
Weight in grams (batteries included)
Size (LxWxH) (mm)
Guidelines
  • CE MARK
  • EMC: IEC/EN61326
  • IEC/EN61010-1

STANDARD ACCESSORIES

OPTIONAL ACCESSORIES
